B1C0E-13: Microphone Signal Input Open Circuit
Overview:
Write up for the system:-
Microphone – This microphone is located at the roof top of vehicle. It is used for executing voice commands and
BT (Bluetooth) connected phone calls.
ISO Code
B1C0E-13
Customer Symptom
1. Caller is unable to hear User voice that is on vehicle
during active call using BT connected phone.
2. HU is unable to accept user given Voice recognition
(VR) commands.
Fault Effects (On Vehicle)
No
Lamp Status (If Any)
No
Fault Detection Condition
1. Caller is unable to hear User voice that is on vehicle
during active call using BT connected phone.
2. HU is unable to accept user given Voice recognition
(VR) commands.
3. This DTC gets logged when connection between
microphone signal input and Head Unit is Open
circuit.
Normal Operating Condition
1. User will be able to make BT hands free phone calls.
2. User will be able to launch the outgoing calls using
voice commands.
Probable Trouble Area
x
Wiring harness between HU and microphone
x
HU Connector and connector terminals
x
Microphone connector and its terminals
x
Intermittent connector and their terminals
Healing Condition
None
