Applicability:-
Level A MIC DTC Applicability:
Fault Scenarios
MIC GND short
to Battery
MIC IN Short to
GND
MIC IN short to
Battery
MIC IN Open
B1COD-12
B1C0E -11
B1C0E -12
B1C0E -13
Microphone Signal
Input (MIC IN)
Open
√
Short to Battery
√
√
Short to Ground
√
Microphone
Ground (MIC GND)
Short to Battery
√
√
Level B MIC DTC Applicability:
Fault Scenarios
MIC GND short
to Battery
MIC IN Short to
GND
MIC IN short to
Battery
MIC IN Open
B1COD-12
B1C0E -11
B1C0E -12
B1C0E -13
Microphone Signal
Input (MIC IN)
Open
√
Short to Battery
√
Short to Ground
√
Microphone
Ground (MIC GND)
Short to Battery
√
Inspection Method (If any):-
NO
