C1324 - 00: Control module input power “A” circuit voltage above critical threshold
Overview:
This fault will come in engine running condition only
Input Power "A" is the Voltage Supply from battery
ISO Code
C1324-00
Customer Symptom
No PSCM functionality (Heavy steering)
Fault Effects (On Vehicle)
No assistance
Lamp Status (If Any)
Warning Lamp ON
Fault Detection Condition
Short circuit within supply lines
Normal Operating Condition
PSCM should provide assist if steering wheel is steered after
engine is cranked. Normal operating range:
ECU will be awake from 6V to 16 V.
Full assistance is b/w 10V to 16V
Reduced assistance is b/w 8.7V to 10V
Drive motor “A” phase current b/w 0 to 60 Amp
Probable Trouble Area
Fuse box
Battery Supply line
Alternator overcharging
Healing Condition
NA
Component Details:
NA
Preliminary Checks:
1. Voltage at the battery terminals should be greater than 11.5V and less than 16V.
2. PSCM power supply connector should have voltage between 11.5 to 16 volts for full assistance.
3. Check battery cable and PSCM connector terminals for damage.
4. Check PSCM ECU for pin bend/damage.
5. Alternator output voltage should be between 13.5 V to 14.5 V in engine running condition.
