PSCM
DTC Troubleshooting Guide for Nexon
Version: 1.1
Date: 21/06/2017
Author: E&E Chassis - ERC
Page: 97 of 156
Copyright ©
TATA MOTORS Ltd.
This document must not be used in any way, such as copying and redistributing to third parties, without the consent of author.
C1325 - 00: Control module internal – low critical internal system failure warning
Overview:
ISO Code
C1325-00
Customer Symptom
No warning lamp, No heavy steering
Fault Effects (On Vehicle)
Default assistance
Lamp Status (If Any)
Warning Lamp OFF
Fault Detection Condition
NA
Normal Operating Condition
PSCM should provide assist if steering wheel is steered after
engine is cranked. Normal operating range:
ECU will be awake from 6V to 16 V.
Full assistance is b/w 10V to 16V
Reduced assistance is b/w 8.7V to 10V
Drive motor “A” phase current b/w 0 to 60 Amp
Probable Trouble Area
Internal ECU failure
Healing Condition
NA
Component Details:
NA
Preliminary Checks:
NA
