Trouble Shooting:
Voltage
fluctuates
between 0V
and 14V?
A
Yes
Disconnect PSCM ECU power supply
connector. Check voltage b/w pin 1& 2.
(Refer Connector View & Information)
No
Is DTC
Present?
Yes
No
Stop
1. Connect the TML Diagnostic Tool.
2. Turn the Ignition ON
3. Check the status of DTC’s (Memorized/Current)
4. Record the DTC & Clear
5. Turn Ignition OFF & ON.
6. Read ECU parameters 7001(Control Module Input
Power “A”) using diagnostic tool
Range: 9 to 16 V.
7. Verify If
U1324-00
is present
Replace wiring harness
(Vehicle side)
Check resistance of Under bonnet fuse
box (60 Amp).
Is it infinity
/Showing No value
(fuse is blown)?
Yes
No
Replace the respective
fuse
