TML Park Distance Controller (PDC) ECU DTC
Troubleshooting guide for Nexon
Version: 0.2
Date: 08Jun17
Author:
Ravi Teja
Page: 82 of 123
Copyright ©
TATA MOTORS Ltd.
This document must not be used in any way, such as copying and redistributing to third parties, without the consent of
author.
U161A – 64 :HU System Customization Data ACK
Overview:
Write up for the system:-
On IGN ON, HU should configure PDC functionality by sending valid PDC User customization
setting data to PDC ECU.
Pre-Check Points:
NO.
Trouble Shooting:-
Below given flowcharts guides to troubleshoot the fault:
ISO Code
D61A – 64
Customer Symptom
When user activates Park assist using Reverse
gear/PDC Fascia Switch/HU, Park assist functionality
will not be available and “critical fault” Screen will be
displayed on HU.
Fault Effects (On Vehicle)
Park Assist functionality will not available to the user.
Lamp Status (If Any)
No
Fault Detection Condition
1. When user activates Park assist using
Reverse gear/PDC Fascia Switch/HU, Park
assist functionality will not be available.
2. This DTC gets logged when invalid PDC User
customization setting data is received from
Head Unit.
Normal Operating Condition
When user activates Park assist using Reverse
gear/PDC Fascia Switch/HU, Park assist functionality
will be available on HU.
Probable Trouble Area
x
PDC ECU Internal Software
Healing Condition
None
