Trouble Shooting:-
Step Checks
IF YES
IF NO
1.
Perform the Immo paring operation through diagnostic tool.
Is pairing successful?
Start the vehicle and
Handover the
vehicle back to
customer
Contact the service
technician
2
Fault still persists?
Repeat the above
procedure for fault
rectification.
Fault still persists
then contact the
service technician
Handover the
vehicle to the
customer.
DTC’s confirmation:-
After rectification, ensure the following points by referring engine parameters using TML diagnostic tool before
handing over to customer.
Recheck the fault using TML Diagnostic tool, Fault shall not appear.
Turn the Ignition ON, Immo lamp shall get turned OFF.
Clear the DTC’s in EMS & Immo and Crank the vehicle, vehicle shall start and Immo lamp shall turn OFF at ignition
On condition
