OSPREY- Application

DTC Troubleshooting Data

Version: 4.0

Date: 10-02-2017

Prepared by: Mithipati Prasad

Checked by: G S Raju / Senthilnathan S

Page: 40 of 654

Copyright ©

TATA MOTORS Ltd.

This document must not be used in any way, such as copying and redistributing to third parties, without the consent of author.

Trouble Shooting:

Step Checks

IF YES

IF NO

1.

Check the clutch sensor gap between the Sensor Magnet

and pedal as per the Sensor mounting specification. Any

deviations found?

Mount the sensor as

per the instructions

Go to Next step

2.

Is there continuity exists between 40% clutch switch pin 3

and EMS ECU pin 50 && 90% clutch switch pin 2 and EMS

ecu pin 17.

Go to step 3

Rectify the wiring

harness

connections as per

the schematic

3

Check whether EMS ECU pins 17 / 50 are shorted to

battery supply / Ground

Rectify the wiring

harness connections

as per the schematic

Go to Next step

5

Are there any pins damaged at EMS ECU Connector

Replace the

connector

Go to step 6

6

Are there any pins backed out from the EMS ECU

Connector

Rectify/Replace

Connectors

Go to Step 7

7

Is clutch Sensor connector damaged or pins got backed out Rectify/Replace

Connector

Go to step 8

8

Are there any EMS ECU pins bent / damaged?

Rectify / Call Hot

Line

Go to Next step

9

Fault Still Persists?

Replace Clutch

Sensor

Go to Next step

10 Fault Still Persists after Clutch Sensor replacement?

Call Hot Line

Follow the above

procedure again for

fault rectification

DTC’s confirmation (checks before handing over vehicle to customer):

Read the Clutch State parameter in Diagnostic tool:

x

When pedal is not pressed

Clutch Engaged

x

When Pedal is partially pressed

Clutch Disengaged

x

When the pedal is fully pressed

Clutch Fully disengaged
