OSPREY- Application
DTC Troubleshooting Data
Version: 4.0
Date: 10-02-2017
Prepared by: Mithipati Prasad
Checked by: G S Raju / Senthilnathan S
Page: 41 of 654
Copyright ©
TATA MOTORS Ltd.
This document must not be used in any way, such as copying and redistributing to third parties, without the consent of author.
Schematic:
EMS ECU
50
17
Dual Position
Clutch Sensor
Extended Travel Input
Top Travel Input
Supply
3
2
1
4
