OSPREY- Application

DTC Troubleshooting Data

Version: 4.0

Date: 10-02-2017

Prepared by: Mithipati Prasad

Checked by: G S Raju / Senthilnathan S

Page: 253 of 654

Copyright ©

TATA MOTORS Ltd.

This document must not be used in any way, such as copying and redistributing to third parties, without the consent of author.

Trouble Shooting:

Step Checks

IF YES

IF NO

1.

Check for any CAN bus related DTC’s

Rectify them by

Following their

rectification

Procedure

Go to Step 2

2.

Check for any Vehicle Speed sensor related faults in

Instrument Cluster ECU(Non-ABS vehicle) & in ABS

ECU(ABS variant)

Rectify them by

Following their

rectification

Procedure

Go to Step 3

3.

Check for any pin back out at CAN pin 18/19of EMS

connector or back out at speed sensor connector pin.

Rectify/Replace the

Connector

Go to Step 4

4.

Fault Still Persists?

Replace Vehicle

Speed Sensor. If

fault still persists

then replace Ecu

Repeat the

procedure for Fault

Confirmation

DTC’s confirmation (checks before handing over vehicle to customer):-

x

Visually check the speedometer gauge on instrument cluster and vehicle speed signal (with gear information)

status at diagnostic tool at different vehicle speed & at different gear conditions

x

Check the errors at Ignition ON, engine running @ Idle & Flyup with different vehicle speeds also

x

If error present, then rectify the errors. Confirm that there are no errors logged by EMS before handing over

vehicle to customer

Circuit Schematic Diagram:
