OSPREY- Application

DTC Troubleshooting Data

Version: 4.0

Date: 10-02-2017

Prepared by: Mithipati Prasad

Checked by: G S Raju / Senthilnathan S

Page: 525 of 654

Copyright ©

TATA MOTORS Ltd.

This document must not be used in any way, such as copying and redistributing to third parties, without the consent of author.

x

Check the brake switch setting; if the problem is with the brake setting perform the necessary repairs.

x

Check whether the brake pedal is moving freely.

x

Loose/ Damaged Connections between APM sensor and EMS ecu.

x

Loose/ Damaged Connections between Brake switch connector and EMS ecu.

x

Check for back out of pins at both APM sensor connector, Brake switch connector and ECU connector.

x

Check for damage of pins at both APM sensor connector, Brake switch connector and ECU connector.

Trouble Shooting:

Step Checks

IF YES

IF NO

1.

Is there any rust/oxidization observed on Sensor Terminals Clean the Rust or

repair or replace

Go to Step 2

2.

Is there wiring harness electrical continuity between ECU

pins 37,78, 16 &Accelerator pedal Sensor connector pins

4,2,3.

Go to Step 3

Establish continuity

by rectifying

harness

connections as per

the circuit

schematic

3

Is there wiring harness electrical continuity between ECU

pins 38,76, 59 &Accelerator pedal Sensor connector pins

6,1,5.

Go to Step 4

Establish continuity

by rectifying

harness

connections as per

the circuit

schematic

4

Is there continuity exists between Main Brake switch pin X

and EMS ECU pin 39 && Main brake switch pin X and

battery supply.

Go to Step 5

Establish continuity

by rectifying

harness

connections as per

the circuit

schematic

5

Is there continuity exists between Brake redundant switch

pin X and EMS ECU pin 13 && redundant brake switch pin

X and ground

Go to Step 6

Establish continuity

by rectifying

harness

connections as per

the circuit

schematic

6

Whether EMS ECU pins 39 / 13 shorted to battery supply /

Ground?

Repair the harness

as per the schematic Go to Step 7

7. Are there any pins damaged at Sensor/EMS ECU

Connector

Replace the

connector or wiring

harness

Go to step 8

8

Are there any pins backed out from the Sensor/EMS ECU

Connector

Rectify/Replace

Connectors

Go to Step 9

9

Is APM Sensor Supply Pin 78 Short circuited to

Battery/GND or open?

Repair the harness

as per the schematic Go to step 10

10 Is APM Sensor Signal Pin 37/38 Short circuited to

Repair the harness

Go to Step 11
