Trouble Shooting:
Step Checks
IF YES
IF NO
1
Is there any rust/oxidization observed on Sensor Terminals Clean the Rust or
repair or replace
Go to next step
2
Is there wiring harness electrical continuity between ECU
pins 75, 56,20 & AC pressure Sensor connector pins 1, 2, 3. Go to next step
Establish continuity
by rectifying
harness
connections as per
the circuit
schematic
3
Are there any pins damaged at Sensor/EMS ECU Connector
Replace the
connector or wiring
harness
Go to next step
4
Are there any pins backed out from the Sensor/EMS ECU
Connector
Rectify/Replace
Connectors
Go to next step
5
Is Sensor Supply pin 75, Short circuited to GND/Battery.
Repair the harness
as per the schematic
Go to next step
6
Is Sensor Signal Pin 56, Short circuited to GND/Battery.
Repair the harness
as per the schematic
Go to next step
7
Is sensor physically Damaged
Replace Sensor
Go to next step
8
Fault Still Persists?
Call Hotline.
Follow the steps
again for
reconfirmation
DTC’s confirmation:
After rectification, ensure the following points before handing over to customer.
x
Measure the AC refrigerant pressure, AC refrigerant pressure shall be in the range of 2 to 32 bar.
x
Ensure that no faults are logged in EMS before handing over vehicle back to customer
