yϭϬϰ KƐƉƌĞLJ /ŶƐƚƌƵŵĞŶƚ ůƵƐƚĞƌ
d dƌŽƵďůĞƐŚŽŽƚŝŶŐ ĂƚĂ
sĞƌƐŝŽŶ͗ ϭ͘ϯ
ĂƚĞ͗ ϮϬͲDĂƌĐŚͲϭϳ
Author: Balaji / Amar /
Nitin / Umapathi /
Deepak
Page: 22 of 138
Copyright ©
TATA MOTORS Ltd.
This document must not be used in any way, such as copying and redistributing to third parties, without the consent of author.
Component Location & Image:-
FLS sensor is located below Co-Driver seat & inside the Fuel level tank.
Connector View & Information: -
ĂƚƚĞƌLJ 'ƌŽƵŶĚ ;WŝŶ ŶŽ͘:ϭͲϭϬͿ
&ƵĞů>ǀů^ĞŶƐ^ŝŐ ;WŝŶ ŶŽ͘:ϭͲϭϭͿ
^ŝŐŶĂů 'ƌŽƵŶĚ ;WŝŶ͘EŽ͘:ϭͲϮϰͿ
Inspection Method: -
Check the FLS sensor input to the cluster in Ohms through Multi meter.
