B1936 - 56:- Odometer Values missing From VICM (Immobilizer) for Learning
Overview:-
ISO Code
B1936 -56
Customer Symptom
N/A
Fault Effects (On Vehicle)
N/A
Lamp Status (If Any)
N/A
Fault Detection Condition
N/A
Normal Operating Condition
IC shall communicate with the VICM for Odo learning After
ignition On & after ignition Off.
Probable Trouble Area
Related wiring Harness, connector or terminals damaged
IPC connector wired wrong,
Harness wire shorted.
VICM proper working.
Healing Condition
Clearing the Fault. Ignition On/Off
Component Details:-
N/A
Preliminary Checks:-
1. Check Battery Voltage is normal in the range (9v - 16v)
2. Check CAN i/p lines between IPC & VICM for Pinch/Cut.
3. Check ECU & CAN signal pin for oxidation, bending & damage.
4. Check CAN signal at Pin no. J1-5 & J1-6 of the ECU connector.
