PSCM
DTC Troubleshooting Guide for Nexon
Version: 1.1
Date: 21/06/2017
Author: E&E Chassis - ERC
Page: 67 of 156
Copyright ©
TATA MOTORS Ltd.
This document must not be used in any way, such as copying and redistributing to third parties, without the consent of author.
C1314 - 01: Drive motor “A” phase current – General electrical failures
Overview:
ISO Code
C1314-01
Customer Symptom
No PSCM functionality (Heavy steering)
Fault Effects (On Vehicle)
No assistance
Lamp Status (If Any)
Warning Lamp ON
Fault Detection Condition
Electrical failures in motor driver circuit/module
Normal Operating Condition
PSCM should provide assist if steering wheel is steered after
engine is cranked. Normal operating range:
ECU will be awake from 6V to 16 V.
Full assistance is b/w 10V to 16V
Reduced assistance is b/w 8.7V to 10V
Probable Trouble Area
Internal ECU motor driver circuit failure
Healing Condition
NA
Component Details:
NA
Preliminary Checks:
1. Check supply voltage.
2. Check all the connections.
