XX = RoutineStatusRecord, RoutineInformation, YY = Response additional
data.
iii. If (XX == 01 && YY==01)
{
Successful
}// END if (XX == 01 && YY==01)
Else
{
Unsuccessful
}// END else if (XX == 01 && YY==01)
17)Write variant specific configuration data to PEPS against PLM server.
18) Provide PEPS ECU reset (service $11 01) and wait for 1 second.
19)Reset PEPS-BCM encryption counter in BCM (using tester tool).
x
PEPS-BCM Encryption Counter Reset Procedure BCM:
i. Send service request $ 31 01 34 0C
ii. Check Start routine response of the routine 71 01 34 0C XX YY.
XX = RoutineStatusRecord, RoutineInformation, YY = Response additional
data.
iii. If (XX == 01 && YY==01)
{
Successful
}// END if (XX == 01 && YY==01)
Else
{
Unsuccessful
}// END else if (XX == 01 && YY==01)
20) Provide BCM ECU reset (service $11 01) and wait for 1 second.
