Successful
}// END if (XX == 01 && YY==01)
Else
{
Unsuccessful
}// END else if (XX == 01 && YY==01)
28) Lock AES_SK code in BCM.
x
AES_SK Locking Procedure BCM:
i. Send service request $ 31 01 34 0A
ii. Check Start routine response of the routine (71 01 4F 0A XX YY). XX =
RoutineStatusRecord, RoutineInformation, YY = Response additional data
iii. If (XX == 01 && YY==01)
{
Successful
}// END if (XX == 01 && YY==01)
Else
{
Unsuccessful
}// END else if (XX == 01 && YY==01)
29) Lock AES_SK code in EMS ECU. Please refer EMS diagnostic specification to lock
AES_SK code in EMS ECU.
30)Clear all DTC (parallel request to all ECUs)
31)Read and confirm variant specific configuration data of PEPS against PLM server $22 all
DIDs". If there is any mismatch, Rectify the problem and start the execution from the
beginning.
