Trouble Shooting:
Step Checks
IF YES
IF NO
1.
Check for faults P 0101, P0102; P0103; P0104, P0642,
P0643
Follow rectification
process for the
faults, before
proceeding further
Go to Step 2
2. Check for electrical continuity between ECU to AMF
connector as per circuit schematic
Go to Step 3
Establish continuity
by rectifying
harness
connections as per
the circuit
schematic
3. Are there any pins damaged at EMS ECU Connector
Replace the
connector or wiring
harness
Go to step 4
4
Are there any pins backed out from the EMS ECU
Connector
Rectify/Replace
Connectors
Go to Step 5
5
Fault Still Persists?
Replace relay and
then if Fault still
persists then Call
Hot Line
Follow the steps
again for
reconfirmation
DTC’s confirmation:
After rectification, ensure the following points by referring engine parameters using TML diagnostic tool before handing
over to customer.
x
Check the Air mass flow sensor reading at ignition key on shows 636 mg/st.
x
Air mass flow reads < 700 mg/st when the engine is at idle.
x
Air mass flow reads > 800 mg/st when the engine is at fly-up.
