Trouble Shooting:
Step Checks
IF YES
IF NO
1.
Check whether the EMS ECU is getting power supply and
GND
Go to step 2
Rectify wiring
Harness as per the
schematic if found
faulty
2. Are there any pins damaged at EMS ECU Connector
Replace the
connector or wiring
harness
Go to step 3
3
Are there any pins backed out from the EMS ECU
Connector
Rectify/Replace
Connectors
Go to Step 4
4
Fault Still Persists?
Fault still persists
then Replace EMS
ECU
Follow the steps
again for
reconfirmation
DTC’s confirmation (checks before handing over vehicle to customer):
After rectification ensure the following before handing over to customer.
x
Clear the errors & confirm that no any errors present in ECU
