Trouble Shooting:
Step Checks
IF YES
IF NO
1 Check continuity between ECU and Boost Temperature
sensor as per circuit schematic. Any issue found?
Follow electrical
continuity check
procedure.
Replace/rectify
harness if required
Go to Next Step
2. Are there any pins damaged at EMS ECU Connector
Replace the
connector or wiring
harness
Go to Next Step
3
Are there any pins backed out from the EMS ECU
Connector
Rectify/Replace
Connectors
Go to Next Step
4
Check whether the EMS ECU pin 73 is short circuited to
Battery / Ground
if problem identified
replace the AMF
sensor also rectify
the wiring harness.
Go to Next Step
5
Fault Still Persists?
If Fault still persists
then call hotline
Follow the steps
again for
reconfirmation
DTC’s confirmation (checks before handing over vehicle to customer):
x
Check the errors at Ignition ON, engine running @ Idle & Fly-up with different vehicle speeds also
x
If error present, then rectify the errors.
x
Confirm that there is no error logged in EMS before handing over vehicle to customer.
