ECU Pin assignment:-
, D Z
Pin No.
Pin Name
Description
1
CAN_H
CAN High
2
CAN_L
CAN Low
7
A_GND
Common Switch GND
12
V bat
Supply Voltage Battery
23
GND
Power GND
Inspection Method:-
N.A
