DTC Troubleshooting Guide for Nexon
Version: 1.1
Date: 21/06/2017
Author: E&E Chassis - ERC
Page: 53 of 156
Copyright ©
TATA MOTORS Ltd.
This document must not be used in any way, such as copying and redistributing to third parties, without the consent of author.
DTC’s confirmation:
After rectification, ensure the following points before handing over the system to the customer.
1. Replacement of steering column as per
annex_2
.
2. Rotate steering wheel when vehicle is in static condition, it should be easily rotated by the driver.
3. Active return and end stop functionalities should be available.
Circuit Schematic Diagram:
NA
Component Location & Image:
NA
Connector Location:
NA
Connector View & Information:
NA
Inspection Method:
NA
