3
Fault Still persists?
Call Hotline
Repeat the above
steps for fault
confirmation
schematic.
4.
Check whether the EMS ecu pin 32/ 68 is short circuited to
Ground.
Rectify the wiring
harness connections
as per the schematic
Go to step 6
5.
Fault still persists?
Replace economy
mode switch. IF fault
still persists then
Call hot line
Confirm the above
procedure for fault
Rectification.
DTC’s confirmation:
After rectification, ensure the following points by referring engine parameters using TML diagnostic tool before handing
over to customer.
x
Turn the Ignition OFF and then turn it ON. Recheck the fault, Fault shall not reappear.
Circuit Schematic:
NA
Component location & Connector Location Image:
NA
