Nexon Gasoline – EMS ECU Bosch
DTC Troubleshooting Manual
Version: 0.1
Date: 26-08-2017
Prepared By: Sunu S Babu/Yogesh Jadhav
Checked By: Yeshwant Jadhav
Approved By: Satish Kumar
Document Part No: 2921 02 224 A1736
Page: 6 of 1203
Copyright ©
TATA MOTORS Ltd.
This document must not be used in any way, such as copying and redistributing to third parties, without the consent of author.
P0351-12: Ignition Coil “A” Primary Control Circuit High– Circuit Short to Battery .......................................... 544 P0351-14: Ignition Coil “A” Primary Control Circuit High– Circuit Short to Ground or Open .......................... 550 P0352-12: Ignition Coil “B” Primary Control Circuit High– Circuit Short to Battery .......................................... 556 P0352-14: Ignition Coil “B” Primary Control Circuit High– Circuit Short to Ground or Open .......................... 562 P0353-12: Ignition Coil “C” Primary Control Circuit High– Circuit Short to Battery .......................................... 568 P0353-14: Ignition Coil “C” Primary Control Circuit High– Circuit Short to Ground or Open ......................... 574 P0363-92: Cylinder Selective Fuel Cutoff Active due to Catalyst Damaging Misfire - Performance or Incorrect Operation .................................................................................................................................................... 580 P0365-13: Camshaft Position Sensor “B” Circuit – Circuit Open ........................................................................ 586 P0366-78: Camshaft Position Sensor “B” Circuit Range/Performance – Alignment or Adjustment Incorrect ...................................................................................................................................................................................... 593 P0369-1F: Camshaft Position Sensor “A” Circuit Intermittent – Circuit Intermittent ........................................ 600 P0420-92: Catalyst System Efficiency below Threshold – Performance or Incorrect Operation ................... 607 P0444-13: Evaporative Emission System Purge Control Valve – Circuit Open ............................................... 609 P0458-11: Evaporative Emission System Purge Control Valve Circuit Shorted to ground– Circuit Short to Ground ......................................................................................................................................................................... 614 P0459-12: Evaporative Emission System Purge Control Valve Circuit Shorted to battery– Circuit Short to Battery .......................................................................................................................................................................... 619 P0480-13: A/C Fan 1 Control Circuit– Circuit Open ............................................................................................. 624 P0481-13: Radiator Fan High Speed Relay Control Circuit – Circuit Open ...................................................... 628 P0500-8: Vehicle Speed Sensor “A”– Bus Signal / Message Failures .............................................................. 632 P0500-84: Vehicle Speed Sensor “A”– Signal Below Allowable Range ............................................................ 637 P0501-92: Vehicle Speed Sensor “A” Range/Performance– Performance or Incorrect Operation .............. 642 P0504-2F: Brake switch “A/B” Correlation – Signal Erratic ................................................................................. 647 P0504-35: Brake switch “A/B” Correlation – Signal Erratic – General Electrical Failure Signal High Time > Maximum ..................................................................................................................................................................... 652 P0512-9: Starter Request Circuit – Component Failures ..................................................................................... 657 P0513-05: Incorrect Immobilizer Key – System Programming Failure .............................................................. 661 P0531-21: A/C Refrigerant Pressure Sensor “A” Circuit Range/Performance - Signal Stuck Low ............... 665 P0531-22: A/C Refrigerant Pressure Sensor “A” Circuit Range/Performance - Signal Stuck High .............. 671 P0532-21: A/C Refrigerant Pressure Sensor “A” Circuit Low ............................................................................. 677 P0533-22: A/C Refrigerant Pressure Sensor “A” Circuit High ............................................................................. 683 P0562-16: System Voltage Low - Circuit Voltage Below Threshold .................................................................. 689
